TrikLits – G42
TrikLits – G42
Minleon’s flagship RGB strand, is individually controllable 2 x RGB(W) pixels for nice even colors and brightness. Your favorite Mesh controller, or Minleon WEC or NEC stock controllers create smooth effects with a 16-bits per channel.Sturdy, professional and commercial construction with insulated wire for 4-season, permanent installations. Custom lengths and pitches available in 3 different diameter bulbs.
Options
Diodes/channels: RGB or RGBW
Pixel spacing: 4″, 6″ or 12″
Light counts: 5, 10, 25, or custom with MOQ
Wire color: black, green, white
Dimming curve: 16-bit (RGB+) or 8-bit (RGB-SE)
Thru connector: female thru or terminated with eye-hole loop
| Output | |
|---|---|
| LED Type | SMD5050 |
| LED Channels | R-G-B |
| LED Count | 16-bit, 65,536 dimming levels* |
| LED Quantity | 2 |
| Viewing Angle | 360-degrees |
| Control | Individually Addressable |
| Control Systems | MeshTek 1-Port and 4 Port Controllers with BlueRoots App |
| Max Lights Before Power Injection | Approx. 125L |
| Max Distance Before Power Injection | Approx. 100-feet |
| Electrical & Safety | |
| Input Voltage | 12 VDC |
| Current | 0.028 Amps |
| Power | 0.336 Watts |
| Wire | 22 AWG, 3C, UV protected |
| Inline Power Injection | Via Mesh Power T+’s & RGB+5A-12V |
| Certifications | (c)UL listed, CE |
| Physical | |
| Diameter | 42 mm |
| Weight | Approx. 1.2 oz. per bulb |
| Housing | Polycarbonate |
| Bulb Style | Frosted |
| Connector Type | LLT twist-lock |
| Operating Temperature | Neg -20 to +50°C / Neg -4 to +122°F |
